SF Series

Shangfeng is willing to cooperate sincerely with all customers to grow and develop together.

Product Categories

Recent Posts

SF Series

Introduction
The SF series is a comprehensive range of electrical products designed to meet various industrial needs. Known for its reliability and versatility, the SF series includes Industrial Plugs, Surface Mounted Sockets, Flush Mounted Sockets, Flush Mounted Angled Sockets, Connectors, and Appliance Sockets. These products are engineered to provide robust performance in demanding environments, making the SF series an ideal choice for a wide array of applications.

Product Attributes

The SF series products are designed with precision and high-quality materials to ensure long-lasting performance. They feature durable construction, easy installation, and safety mechanisms to prevent accidental disconnections. The SF series offers a range of options to cater to different electrical requirements and installation preferences, ensuring compatibility and ease of use.

Product Advantages

1. Durability and Reliability
   - High-Quality Materials: The SF series products are made from robust materials that can withstand harsh industrial conditions, ensuring longevity and consistent performance.
   - Safety Features: Built-in safety mechanisms, such as secure locking systems, prevent accidental disconnections and enhance user safety.

2. Ease of Installation
   - User-Friendly Design: The SF series includes products with designs that facilitate quick and easy installation, reducing downtime and maintenance costs.
   - Versatile Mounting Options: Whether you need surface-mounted or flush-mounted installations, the SF series provides flexible solutions to meet different installation needs.

3. Wide Range of Applications
   - Industrial Compatibility: The SF series products are suitable for various industrial applications, from factories to warehouses, providing reliable power connections.
   - Adaptability: These products can be used in different environments, making the SF series a versatile choice for many sectors.

Product Features

1. Comprehensive Product Range
   - Diverse Offerings: The SF series includes Industrial Plugs, Surface Mounted Sockets, Flush Mounted Sockets, Flush Mounted Angled Sockets, Connectors, and Appliance Sockets, covering a broad spectrum of electrical needs.
   - Standard Compliance: All products in the SF series comply with international standards, ensuring safety and performance.

2. Robust Construction
   - Impact Resistance: Designed to withstand physical impacts, the SF series products are ideal for use in tough industrial environments.
   - Weatherproof Design: Many products in the SF series are designed to resist weather elements, making them suitable for both indoor and outdoor use.

3. Safety and Security
   - Secure Connections: The SF series products feature secure connection mechanisms to prevent accidental disconnections and ensure continuous power supply.
   - Protective Features: Safety shutters and grounding mechanisms are incorporated to protect users and equipment.

Product Applications

1. Industrial Environments
   - Factories and Warehouses: The SF series products are ideal for use in factories and warehouses where reliable and durable electrical connections are essential for operations.

2. Commercial Settings
   - Office Buildings: The versatile mounting options of the SF series make it suitable for office buildings, providing safe and efficient power distribution.

3. Outdoor Installations
   - Construction Sites: The weatherproof and robust nature of the SF series products makes them for temporary or permanent installations on construction sites, ensuring safety and reliability.

Conclusion
The SF series stands out as a comprehensive solution for various electrical needs in industrial, commercial, and outdoor settings. With its focus on durability, ease of installation, and safety, the SF series offers a reliable and versatile choice for professionals. Whether you need Industrial Plugs, Surface Mounted Sockets, Flush Mounted Sockets, Flush Mounted Angled Sockets, Connectors, or Appliance Sockets, the SF series delivers consistent performance and adaptability across different applications.

SF-013-4 SF-023-4 Industrial Plug

SF-013-4 SF-023-4

Earth contact position 6h
Rated current(A) 16 32
Pole 3
Dimension(mm) a 122 139
b 59 75
c 51 64
Ø 6 8
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 110-130V~2P+E
Protection degree:  IP44

SF-013 SF-023 Industrial Plug

SF-013 SF-023

Earth contact position 6h
Rated current(A) 16 32
Pole 3
Dimension(mm) a 122 139
b 59 75
c 51 64
Ø 6 8
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 220-240V~2P+E
Protection degree:  IP44

SF-014 SF-024 Industrial Plug

SF-014 SF-024

Earth contact position 6h
Rated current(A) 16 32
Pole 4
Dimension(mm) a 122 139
b 65 75
c 55 64
Ø 6 8
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 380-415V~3P+E
Protection degree:  IP44

SF-015 SF-025 Industrial Plug

SF-015 SF-025

Earth contact position 6h
Rated current(A) 16 32
Pole 5
Dimension(mm) a 130 143
b 72 84
c 64 70
Ø 8 8
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 220-380V~/240-415V~3P+N+E
Protection degree:  IP44

SF-033 SF-043 Industrial Plug

SF-033 SF-043

Earth contact position 6h
Rated current(A) 63 125
Pole 3
Dimension(mm) a 231.5 293
b 110 125
c 16-38 30-50
Ø 110 125
Cable nominal cross-section area(mm²) 6-16 16-50
Contact us
Current(A):  16A. 32A
Voltage(V): 220-240V~2P+E
Protection degree:  IP67

SF-034 SF-044 Industrial Plug

SF-034 SF-044

Earth contact position 6h
Rated current(A) 63 125
Pole 4
Dimension(mm) a 231.5 293
b 110 125
c 16-38 30-50
Ø 110 125
Cable nominal cross-section area(mm²) 6-16 16-50
Contact us
Current(A):  16A. 32A
Voltage(V): 380-415V~3P+E
Protection degree:  IP67

SF-035 SF-045 Industrial Plug

SF-035 SF-045

Earth contact position 6h
Rated current(A) 63 125
Pole 5
Dimension(mm) a 231.5 293
b 110 125
c 16-38 30-50
Ø 110 125
Cable nominal cross-section area(mm²) 6-16 16-50
Contact us
Current(A):  63A. 125A
Voltage(V): 220-380V~/240-415V~3P+N+E
Protection degree:  IP67

SF-013L-4 SF-023L-4 Industrial Plug

SF-013L-4 SF-023L-4

Earth contact position 4h
Rated current(A) 63 32
Pole 3
Dimension(mm) a 141 178
b 59 75
c 51 64
Ø 8 10
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  63A. 125A
Voltage(V): 110-130V~2P+E
Protection degree:  IP44

SF-013L SF-023L Industrial Plug

SF-013L SF-023L

Earth contact position 6h
Rated current(A) 16 32
Pole 3
Dimension(mm) a 141 178
b 59 75
c 51 64
Ø 8 10
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 220-240V~2P+E
Protection degree:  IP44

SF-014L SF-024K Industrial Plug

SF-014L SF-024K

Earth contact position 6h
Rated current(A) 16 32
Pole 4
Dimension(mm) a 141 178
b 65 75
c 55 64
Ø 8 10
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 380-415V~3P+E
Protection degree:  IP44

SF-015L SF-025L Industrial Plug

SF-015L SF-025L

Earth contact position 6h
Rated current(A) 16 32
Pole 5
Dimension(mm) a 169 181
b 72 84
c 64 70
Ø 10 10
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 220-380V~/240-415V~3P+N+E
Protection degree:  IP44

SF-113-4 SF-123-4 Industrial Socket

SF-113-4 SF-123-4

Earth contact position 4h
Rated current(A) 16 32
Pole 3
Dimension(mm) a 135 153
b 92 102
c 71 71
d 50 65
e 57 57
f 20 20
g 32.5 32.5
h 6.5 6.5
Cable nominal cross-section area(mm²) 1-2.5 2.5-6
Contact us
Current(A):  16A. 32A
Voltage(V): 110-130V~2P+E
Protection degree:  IP44
